Touchdesigner

In Touchdesigner DMX data is sent to the daisy-chain of fixtures through USB (via an ENTTEC available at the uitleen) or ArtNet.

In Touchdesigner you can create 'presets' called Toxes. You can save these on your computer for easy acces:

DMX Config	TOX	Example fixtures
5 channels:  Intensity Red Green Blue Strobe	ETC_Colorsource_Junior_6ch.tox	ETC ColorSource Spot jr (inventory Blackboxes & klein Zaal) ETC ColorSource Par (inventory Blackboxes)   ColorSource Spot Deep Blue (inventory Kleine Zaal)
6 channels: Red Green Blue White Amber Uv	6CH_Par_RGBWAU.tox   Moving_Head_Ayra_ero406.tox	High End PAR uitleen Theater :   type & DMX traits: Elation SIXPAR 100 >>     Mid Range PAR uitleen Theater  type & DMX traits: 5PXHEX
7 channels: Red Green Blue White Amber Uv Master Dimmer	7CH_Par_RGBWAUI.tox	High End PAR uitleen Theater :   type & DMX traits: Elation SIXPAR 100   Mid Range PAR uitleen Theater type & DMX traits: 5PXHEX  >>
14 channels (see Briteq manual)	Moving_Head_Briteq_BT_W19L10ZOOM_14ch.tox   Moving_Head_Ayra_ero406.tox	.     Briteq BT-W19L10 Zoom (uitleen Oudenoord) WASH, type & DMX traits BT-W19L10 Ayra Ero406  WASH (not in HKU but cheap at BaxShop) ayra_ero_406_led_movinghead_manual_en.pdf

Easy DMX_Out for Artnet (use a merge to connect multiple fixtures, dive in & adjust de DMX out to use another interface)
dmx_out_Artnet_2023.tox

Patch for the Blackbox @ Janskerkhof (to connect with OSC via ipad)
RemoteControlLights (TouchOSC_ArtNet).toe


Check out the WLED page to connect TD to LEDstrips
